The series are features with carbon graphite to bronze. sp.chrom with elastomer "o" ring, PTFE Sealing, The precision ball bearing's for higher pressure and speed, which keep the seal face in perfect alignment The shielded bearing require no relibricetion during operation. Both the series have stainless steel nipple Sizes are available with 2 seal face combination' sinter chang eability for both mono-duo low service
BODY
CI, M.S, S.S, BRASS
NIPPLE
CI, M.S, -304, 316, 410
SEAL RING
Carbon Tungsten Carbide
METAL COMPONENT
S.S 316, SS 304, Hestelloy :C, Alloy 20 Monel etc
SPRING
S.S, Spring Steel
MATING RING
Sp. Chorme Cast, Bronze
OPERATING LIMITS
- WATER PRESSURE : 15 bar
- WATER TEMPERATURE : 150°c
- HOT OIL PRESSURE : 8 Bar
- HOT OIL TEMPERATURE : 150°c
